This 144 Fibers MTP MPO trunk multi-core cable assemblies facilitate rapid deployment of high-density backbone cabling in data centres and other high-density fibre environments, reducing network installation or reconfiguration time and cost. They are used to interconnect cassettes, panels or MTP MPO array cables.
Small diameter and flexible cable construction:
This multimode OM4 fiber MTP MPO trunk assemblies are offered in 12, 24, 36, 48, 72 and 144 fiber versions, using a compact and rugged micro-cable structure.
The compact cables optimise cable pathway use and improve airflow. These MTP MPO trunks are built with the highest quality components and feature a double outer sheath, including an outer rugged sheath for additional protection in ducts and cable trays.
12F Diameter: 4.5 mm
24F Diameter: 4.5 mm
36F Diameter: 9.0 mm
48F Diameter: 9.0 mm
72F Diameter: 11.2 mm
144F Diameter: 15.0 mm
Pulling eye protecters:
Our 144 Fiber MTP MPO trunk cables come with the pulling eye and they feature of speeding up the installation process. In addition, the pulling eye protects the connectors of the multi-MPO fiber optic cables and prevents the cables from twisting during the installation process. Since the pulling eye is strain relived directly onto the outer jacket, it ensures that the pulling stress and strain do not act on the core or the terminations. It allows a tension up to 245N.
Choice of Cable Jacket: PVC (OFNR), LSZH and OFNP cables
Choice of Connectors: MTP Elite, MTP Standard, MPO Low Loss (LL), MPO Standard
Choice of breakout legs length: standard 700mm and staggered breakout legs
