MPO-24 to 4x MPO (Female-Female) Multi-mode OM3 Fiber Fanout Splitter Cable Polarity Type A ; 1m length
Stay ahead of increasing telecommunications application demands and data center space limitations with the MPO connectors.
MTP®/MPO connectors have taken the issues of high data traffic demands and limited working space conditions, and simplified the process of dealing with these challenges using a high density connector and its ability to house 32 fibers.
Using OM3 fiber optics, you are able to transmit data over a 1Gbps link with a 50/125 micron glass fiber over a distance of up to 1000 meters at a wavelength of 850nm, and over a distance of up to 550 meters at 1300nm. For a 40Gbps link, you can transfer data over a distance of up to 300 meters at 850nm.
24-Fiber Single to 4x MTP/MPO Fiber Optic Fanout Cable Features
- 1 MTP/MPO connector on end breaks out to 4 MTP/MPO connectors on the opposite end, housing a total of 24 fibers
- Plenum-rated aqua jacket
- Easy installation and removal with push-pull latching
- Compact design for high fiber-count applications with space limitations
| Connector A | MPO Female (pinless) | Connector B | 4x MPO Female (pinless) |
| Fiber Mode | 24 fibers OM3 50/125 μm | Wavelength | 850/1300 nm |
| Polish Type (MPO) | UPC | Jacket Color | Aqua |
| Minimum Bend Radius | 7.5 mm | RoHS Compliancy Status | Compliant |
| Insertion Loss (LC) | ≤ 0.2 dB | Return Loss (LC) | ≥ 30 dB |
| Insertion Loss (MTP) | 0.75 dB Max. (0.35 dB Typ.) | Return Loss (MTP) | ≥ 20 dB |
| Attenuation at 850 nm | ≤ 2.3 dB/km | Attenuation at 1300 nm | ≤ 0.6 dB/km |
| Jacket OD | 3.0 mm | Cable Jacket | LSZH |
| Installation Tensile Load | 66 N | Long/Short Term Tensile Load | 80 N/240N |
| Storage Temperature | -40°C to 85°C | Operating Temperature | -10°C to 70°C |
