LC-LC Duplex Multimode OM5 Fiber Patchcord for 40G/100G/400G
LC-LC Duplex Multimode OM5 Fiber Patchcord for 40G/100G/400G
LC-LC Duplex Multimode OM5 Fiber Patchcord for 40G/100G/400G
LC-LC Duplex Multimode OM5 Fiber Patchcord for 40G/100G/400G
LC-LC Duplex Multimode OM5 Fiber Patchcord for 40G/100G/400G
LC-LC Duplex Multimode OM5 Fiber Patchcord for 40G/100G/400G
LC-LC Duplex Multimode OM5 Fiber Patchcord for 40G/100G/400G
LC-LC Duplex Multimode OM5 Fiber Patchcord for 40G/100G/400G
LC-LC Duplex Multimode OM5 Fiber Patchcord for 40G/100G/400G

LC-LC Duplex Multimode OM5 Fiber Patchcord for 40G/100G SWDM

$4.40 USD $0.00 USD
Free Worldwide shipping on orders $159
Worry-Free 30 Day Returns ( Return shipping cost on us)
5-Year warranty (Exchange New) & Lifetime warranty (Repair)
Free Trial & Bulk Price Available
Cable Length
1m
2m
3m
5m
10m
20m
30m
40m
Quantity
Only 1000 left
Buy now

LC-LC Duplex Multimode OM5 Fiber Patchcord

OM5 wideband multimode bend insensitive fiber optimized for multi-wavelengths transmission systems operating in the range of 850-950nm, enabling optimal support of emerging Shortwave Wavelength Division Multiplexing (SWDM) applications that reduce parallel fiber count by at least a factor of four to allow continued use of just two fibers (rather than eight) for transmitting 40 Gb/s and 100 Gb/s and reduced fiber counts for higher speeds.
OM5 meets TIA-492AAAE and draft IEC 60793-2-10 A1a.4 requirements while completely backward compatible with existing OM4 networks and applications. It meets RoHS compliant and the fiber patch cord is optically tested for insertion loss to ensure high quality.

Features:

Bend Insensitive Fiber & 7.5mm Min. Bend Radius
Grade A Precision Zirconia Ferrules and Flexible and Abrasion-resistant PVC (Riser) Jacket
100% Backwards Compatibility with the 850nm Wavelength used by OM3/OM4
Compatible with SWDM Solutions in Future Networks
A Wideband Multimode Fiber Solution, Supports at least 4 Wavelengths in 850-950nm Range
Compliant to IEC-61754 and TIA-604 (FOCIS)

Applications:
Fiber Optic Telecommunications
FTTH (Fiber To The Home)
CATV & CCTV
Data Processing Networks
Telecom Equipment
Local Area Networks
