Features:
Hot-pluggable QSFP+/SFP+ form factors
Data rate up to 41.25Gbps
4x 10Gb/s NRZ modulation
QSFP+/SFP+ MSA compliant
Operating case temperature of 0-70°C
Single 3.3V supply voltage
Bit Error Rate (BER) better than 1E-15
RoHS compliant
LSZH (Low Smoke Zero Halogen) jacket
LF (Lead Free) HF (Halogen Free) PCB
SFF-8636 compliant
I2C management interface
Data rate up to 41.25Gbps
4x 10Gb/s NRZ modulation
QSFP+/SFP+ MSA compliant
Operating case temperature of 0-70°C
Single 3.3V supply voltage
Bit Error Rate (BER) better than 1E-15
RoHS compliant
LSZH (Low Smoke Zero Halogen) jacket
LF (Lead Free) HF (Halogen Free) PCB
SFF-8636 compliant
I2C management interface
SPECIFICATION
Connector Type | QSFP+ to 4 SFP+ | Max Data Rate | 40Gbps |
Minimum Bend Radius | 21mm | Wire AWG | 30AWG |
Cable Length | 2m (6.56ft) | Jacket Material | PVC (OFNR) |
Temperature | 0 to 70°C (32 to 158°F) | Protocols | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel |
